CPU

         Dual Intel Xeon Scalable Processors，E5-2600 V3/V4 CPU

Memory

DDR4-2400/2133, 8*DIMM, up to 1TB, support ECC

Display Interface

       1*VGA (AST2400)

Ethernet

2*Intel^® 1Gbps PCIe Ethernet Controller, RJ45

1个 Realtek RTL8211E PHY

GPU

NVIDIA or AMD

USB

2*USB2.0 2*USB3.0

Storage

8*SATA

1*NVME M.2 M-Key （PCIE 2.0*4)

1*MSATA

RAID 0, 1,10 & 5

IPMI

Support for Intelligent Platform Management Interface v2.0

        IPMI 2.0 with virtual media over LAN and KVM over LAN support

        ASPEED AST2400 BMC

Expansion Interface

4*PCIE x16

1*PCIE3.0 x8(single-width in x16 slot)

1*PCIE3.0 x8 (in x8 slot)

Power input

Supports 2 power supplies

1600W 1+1 redundant white gold efficiency power supply

Chassis

Colour：silver      Material Science：aluminium alloy body

Computer

Dimension：685*482.6*177.8mm

Temperature

Operation:10°C~35°C，Storage:-40℃ ~ 70℃

Relative Humidity

Operation:35%~80%

Storage:20%~90%

Server

Windows Sever 2008 R2(64bit)

Windows SBS 2011(64bit)

Windows sever 2012/2012 R2（64bit）

Redhat Enterprise Linux Sever（32bit/64bit）

Suse Enterprise  Linux Sever（32bit/64bit）

Ubuntu Sever  32bit/64bit）

Virtualization

        VMWare ESXI（Target）

        Microsoft Hyper-V（Target）

        Citrix Xen Sever（Target）

        Linux KerneI Virtual Machine（Target）
